PTFE Lined Blind Flange
PTFE lined blind flanges are dual-purpose isolation components designed to either block or allow flow in corrosive piping systems. Featuring a solid steel body with an inert PTFE lining, they provide excellent chemical resistance and leak-proof sealing. The rotating design enables quick line isolation for maintenance or inspection, making them ideal for chemical, pharmaceutical, and process industry applications.
Key Features:
- Dual isolation design
- High chemical resistance
- Leak-proof PTFE lining
- Easy line switching
Specifications:
| Size | Lining Thickness | |
|---|---|---|
| (NB) | (INCH) | (mm) |
| 25NB | 1 | 5 |
| 40NB | 1.5 | 5 |
| 50NB | 2 | 5 |
| 65NB | 2.5 | 5 |
| 80NB | 3 | 5 |
| 100NB | 4 | 5 |
| 125NB | 5 | 5 |
| 150NB | 6 | 5 |
| 200NB | 8 | 5 |
| 250NB | 10 | 8 |
| 300NB | 12 | 8 |
| 350NB | 14 | 8 |
| 400NB | 16 | 8 |
| 450NB | 18 | 8 |
| 500NB | 20 | 8 |
| 600NB | 24 | 8 |
Material Of Construction (MOC):
- Flanges: Material as Per IS 2062 GR B /ASTM A105 Dimensions As per ASME B16.5 #150. JIS or DIN Std Options available
- Lining: Virgin PTFE/Antistatic PTFE in compliance with ASTM F1545- 15a.
